Waste Rubber Grinding Mill Machine
The rubber grinding mill machine is a device that pulverizes 2-6mm pure rubber particles into 40-200 mesh fine rubber powder at normal temperature.
We can provide the working sites of our customers in various countries, please contact us if necessary.
Introduction to Waste Rubber Grinding Machine
The rubber grinding mill is a waste tire grinding machine that pulverizes 2-6mm pure rubber particles into 40-200 mesh fine rubber powder at normal temperature. The structure mainly includes: crushing motor, variable frequency feeding mechanism, grinding disc adjusting mechanism, adding hopper, moving grinding disc, body, main shaft, collecting tube, circulating water cooling system, etc.
Features of Waste Tire Grinding Mill
The tungsten carbide hard alloy is used to make the grinding surface of the grinding disc. The main body of the grinding disc is specially treated by special materials, and has the advantages of impact resistance, high wear resistance, good toughness and long service life.
The waste tyre grinding mill is the horizontal overall structure, and the body of the waste tire grinding machine is processed by the numerical control technology to ensure the accuracy and installation fineness of the equipment. The waste tyre grinding mill for sale is with advantages of compact and reasonable structure, low power, small and light vibration, convenient installation and maintenance.
Our waste tire grinding machine is designed with infrared on-line detection of the feeding mechanism, and the feeding is controlled by PLC program to maximize production. The movement of the grinding disc is slao controlled by the PLC program, which can greatly improve the fineness and quality of finished rubber powder. Yuxi waste rubber grinding machine is with high automation, high output and convenient operation.
The large waste rubber grinding mill is built-in circulating water cooling system, which can effectively reduce the temperature of the moving grinding disc during the working process, so that the rubber powder will not be burned or sticked during the crushing process, so as to greatly improve the working efficiency and the service life of the grinding disc.
Yuxi Machinery is a large waste recycling and processing equipment manufacturer and supplier, and can provide customers customized product in factory price. If you need our machines, please feel free to contact us by leaving a message, thank you so much.
Paramaters of Waste Tyre Grinding Mill Machine
| Model | YX-350 |
| Capacity | 220-380kg/hour |
| Spindle speed | 860(rev / min) |
| Power | 30+0.75+0.06kw |
| Feed size | 2-6MM |
| Discharge size | 40-180 Mesh |
| Weight | 1.53T |
| L*W*H | 1.38*0.75*1.18MM |
